Roof Panel Roll Forming Machine
Key parameters: 0.3–0.8mm thickness, 13–18 forming stations, 10–20m/min forming speed, 5.5–7.5kW main motor. PLC automatic control with touch screen. Hydraulic flying cut for precise length cutting. Roller material: 45# steel, heat-treated and chrome plated. Machine size approx. 6.5×1.5×1.4m, weight 3–5 tons.
Applicable profiles: Trapezoidal, Corrugated, IBR, and other metal roofing panels. Optional configurations: automatic decoiler, stacker, servo drive, embossing device.
Custom designs available per your drawings. Contact us for a quote.
Roof Panel Roll Forming Machine
The roofing sheet roll forming machine is designed for continuous production of metal roofing panels using cold roll forming technology. It is suitable for color steel sheets, galvanized steel, and galvalume steel. The machine features stable performance, high forming accuracy, and is widely used in industrial, commercial, and residential roofing systems.
Main Technical Parameters
| Parameter | Specification |
|---|---|
| Machine Type | Roofing Sheet Roll Forming Machine |
| Suitable Material | Color Steel / Galvanized Steel / Galvalume Steel |
| Material Thickness | 0.3 – 0.8 mm |
| Effective Width | Customized according to profile |
| Feeding Width | As per design drawing |
| Forming Stations | 13 – 18 stations |
| Forming Speed | 10 – 20 m/min |
| Main Motor Power | 5.5 – 7.5 kW |
| Hydraulic Power | 3 – 5.5 kW |
| Control System | PLC Automatic Control with Touch Screen |
| Cutting Method | Hydraulic Flying Cut / Length Cutting |
| Roller Material | 45# steel, heat-treated, chrome plated |
| Transmission System | Chain Drive / Gearbox Drive |
| Power Supply | 380V / 50Hz / 3 Phase (customizable) |
| Machine Size | Approx. 6.5 × 1.5 × 1.4 m |
| Machine Weight | Approx. 3 – 5 tons |
Machine Advantages
High precision roll forming ensures uniform roofing sheet profiles
PLC control system enables easy operation and stable performance
Continuous forming improves production efficiency
Durable rollers and frame ensure long service life
Customizable design according to roofing sheet drawings
Applicable Roofing Sheet Profiles
Trapezoidal Roofing Sheet
Corrugated Roofing Sheet
IBR Roof Sheet
Metal Roofing Panel
Optional Configurations
Automatic Decoiler
Automatic Stacker
Servo Motor Drive
Embossing Device
Remote Technical Support
