Highway Guardrail Roll Forming Machine Manufacturer
Automatic W-Beam & Thrie-Beam Guardrail Production Line Supplier
The highway guardrail roll forming machine is specially engineered for producing W-beam and Thrie-beam crash barriers used in highways, expressways, bridges, municipal roads, and traffic safety projects.
This fully automatic guardrail production line integrates decoiling, leveling, servo punching, roll forming, hydraulic cutting, and automatic stacking into one continuous manufacturing system.
Designed for high efficiency and precision forming, our guardrail roll forming machines comply with ASTM, EN, and JIS standards and have been exported to over 50 countries worldwide.
Why Choose Our Guardrail Roll Forming Machine?
Fully Automatic Guardrail Production System
Equipped with Siemens PLC intelligent control, the entire production process is automated.
Production speed: 8–15 m/min
Only 1–2 operators required
3–5× faster than conventional processing
Stable continuous production
Reduced labor cost
This automatic guardrail forming machine improves manufacturing efficiency and return on investment.
High Precision W-Beam & Thrie-Beam Forming
Our roll forming system ensures consistent panel quality:
Imported alloy steel forming rollers
CNC precision machining
Heat-treated roller surface
Dimensional tolerance within ±0.5 mm
Smooth finished surface without deformation
The produced guardrails meet international installation and road safety standards.
Heavy-Duty Industrial Structure
Built for long-term industrial use:
Q235 heavy steel frame
Integral welded base structure
24-hour continuous operation capability
Siemens & Schneider electrical components
Low maintenance cost and stable performance for large-scale production.
Dual-Profile Flexible Design
One machine supports:
W-beam guardrail production
Thrie-beam guardrail production
Technical flexibility:
Thickness range: 2.5–4.0 mm
Width adjustment: 310–432 mm
Changeover time: within 30 minutes
Roller replacement does not require a crane. Punching layout can be customized according to national highway standards.
Energy-Efficient & Environmentally Friendly
Variable frequency drive control
15–20% energy saving
Low noise operation
No dust pollution
Suitable for modern guardrail manufacturing factories with environmental requirements.
Technical Specifications
| Item | Specification |
|---|---|
| Production Type | W-Beam & Thrie-Beam |
| Production Speed | 8–15 m/min |
| Raw Material | Hot-rolled & Cold-rolled Steel Coil |
| Material Thickness | 2.5–4.0 mm |
| Coil Width | 1000–1250 mm |
| Coil Weight | 3–5 tons |
| Cutting Accuracy | ±0.5 mm |
| Power | 15–30 kW |
| Voltage | 380V / 50Hz (Customizable) |
| Control System | Siemens PLC |
| Machine Weight | 8–15 tons |
| Machine Size | 12000 × 1800 × 1600 mm |
| Warranty | 1 Year |
Applications of Guardrail Roll Forming Machine
This highway guardrail production line is widely used for:
Highway and expressway crash barrier production
Road safety guardrail manufacturing
Municipal infrastructure projects
Bridge and tunnel protection systems
Industrial park and logistics zone safety fencing
Port, railway, and airport barrier production
Ideal for government contractors, road safety engineering companies, and guardrail manufacturers.
Guardrail Roll Forming Machine Price
The price of a highway guardrail roll forming machine depends on:
Required production speed
Automation configuration
Servo punching system
Voltage customization
Automatic stacking system
Packaging solution
As a professional guardrail roll forming machine manufacturer, we provide factory-direct pricing and customized solutions.
Contact us to receive a detailed quotation and layout plan.
Why Choose Us as Your Guardrail Roll Forming Machine Supplier?
10+ years of roll forming machine manufacturing experience
Exported to 50+ countries
CE and ISO certified
Self-developed cutting mold 30% more durable than standard design
Overseas installation and training support
Lifetime technical assistance
Every guardrail roll forming machine is fully tested before shipment to ensure stable operation.
FAQ – Guardrail Roll Forming Machine
Can one machine produce both W-beam and Thrie-beam?
Yes. Our dual-profile design allows quick switching within 30 minutes.
What is the daily production capacity?
Depending on speed configuration, daily output can reach 3,000–6,000 meters.
What standards can your machine meet?
ASTM, EN, and JIS international standards.
Do you provide overseas installation service?
Yes. We offer online support and on-site installation & training services.
What is the delivery time?
Usually 60–90 days depending on configuration.
Get Your Guardrail Roll Forming Machine Quote Today
Looking for a reliable highway guardrail roll forming machine supplier?
Contact us for:
Factory quotation
Technical consultation
Production layout design
Turnkey manufacturing solution
Our sales engineers will respond within 24 hours.
