Drywall Track And Stud Roll Forming Machine
material quality：hot-dip galvanized sheet
producer：Guosu Technology Manufacturing
wxxl2024@gmail.com
Detail
1. Product Overview
The double out light steel keel machine is a high-efficiency cold roll forming equipment for the global construction industry. It is mainly used to produce C/U/Z type light steel keels, studs and tracks, and is widely applied in the wall, floor and roof construction of residential, commercial and industrial buildings. Developed and produced by Changzhou Guosu Technology, this double-head light steel keel cold roll forming machine adopts an advanced PLC control system and modular design. It can form two keel profiles simultaneously in one operation, greatly improving production efficiency and reducing labor costs, and fully meeting the mass production needs of overseas construction enterprises, distributors, contractors and prefabricated building manufacturers.
2. Core Advantages
Double Output Efficiency, Doubled Production Capacity
Compared with traditional single-out light steel keel machines, our double out model can produce two keels of the same or different specifications at the same time, with a maximum production speed of 120 meters per minute. This not only improves production efficiency, but also effectively reduces labor costs, shortens delivery cycles, and helps customers maintain competitiveness in the market.
High Precision Forming, Controllable Quality
The machine is equipped with roller dies made of GCR15 wear-resistant steel, and the forming tolerance is strictly controlled within ±0.5mm. The servo feeding and cutting system achieves precise length control. The produced keels have a smooth surface, no scratches and no deformation, fully complying with international building standards such as ASTM, CE and ISO, and are suitable for high-standard construction projects in Europe, America, Southeast Asia and Africa.
Intelligent Operation, Easy to Get Started
The full-automatic PLC control system is matched with a touch screen operation interface, which can be used without professional programming skills. Parameters such as forming speed, cutting length and keel specification can be set on the touch screen, and support one-key storage and call. New operators can master it proficiently in only 1-2 days, greatly reducing training costs.
Quick Specification Changeover, Strong Versatility
Combined with the production needs of overseas enterprises, the rollers and molds adopt a modular design, which can be quickly disassembled and replaced without complex operations. The specification changeover can be completed in only 30-60 minutes, supporting small-batch and multi-specification production, and flexibly meeting the production needs of various C/U/Z type light steel keels.
Durable Structure, Easy Maintenance
The main frame is integrally welded with thickened steel plates, which has strong load-bearing capacity and is not easy to deform during long-term operation. Key components such as bearings, gears and servo motors are all selected from well-known international brands, which are wear-resistant and corrosion-resistant, have a long service life, and reduce equipment failure rate and daily maintenance costs.
International Certification, Convenient Customs Clearance
The whole machine has passed CE and ISO9001 certifications, and all components meet international safety and environmental protection standards. We provide complete certification documents and customs clearance materials to help overseas purchasers successfully complete import inspection and ensure that the equipment is quickly delivered and put into production.
3. Technical Parameters
Parameter Name | Specification |
Product Model | Double Out Light Steel Keel Machine |
Forming Method | Cold Roll Forming |
Material Thickness | 0.3-1.2mm (Customizable) |
Maximum Production Speed | 120 Meters per Minute |
Forming Tolerance | ±0.5mm |
Control System | PLC Automatic Control + Touch Screen Operation |
Equipment Power | 11-30KW (Customizable According to Requirements) |
Certification | CE, ISO9001 |
Customization Service | Customizable (Adaptable According to Profile Specifications and Production Requirements) |
4. Application Scenarios
Combined with the actual production needs of the global construction industry, the double out light steel keel machine can be widely used in various construction projects, suitable for the production of light steel keels required for residential buildings, commercial office buildings, industrial workshops, warehouses, prefabricated houses and villas. The product is widely recognized by overseas construction contractors, building material distributors, prefabricated building manufacturers and decoration companies, helping customers improve production capacity, reduce costs and seize more market share.
5. About Guosu Technology
Relying on years of experience in R&D and production of cold roll forming equipment, Changzhou Guosu Technology focuses on the R&D, production and sales of cold roll forming equipment, with rich export experience. We have provided high-quality double out light steel keel machines and customized solutions to more than 50 countries and regions around the world (Europe, America, Southeast Asia, Africa, the Middle East, etc.). The company has a professional R&D and after-sales team, providing 24-hour online technical support, on-site installation, commissioning and training services, and providing comprehensive guarantee for overseas customers.
